MEANWELL UHP Series PFC Switching Power Supply - 5V / 12V / 24V / 36V / 48V DC Output Voltage | 200W / 350W / 500W | AC90-264V | UL / CE Certified

Package Included

Version	Package Included
5V 200W 1-Pack	1 × MEANWELL UHP Series Power Supply (5V / 200W), user manual
12V 200W 1-Pack	1 × MEANWELL UHP Series Power Supply (12V / 200W), user manual
24V 200W 1-Pack	1 × MEANWELL UHP Series Power Supply (24V / 200W), user manual
36V 200W 1-Pack	1 × MEANWELL UHP Series Power Supply (36V / 200W), user manual
48V 200W 1-Pack	1 × MEANWELL UHP Series Power Supply (48V / 200W), user manual
5V 350W 1-Pack	1 × MEANWELL UHP Series Power Supply (5V / 350W), user manual
12V 350W 1-Pack	1 × MEANWELL UHP Series Power Supply (12V / 350W), user manual
24V 350W 1-Pack	1 × MEANWELL UHP Series Power Supply (24V / 350W), user manual
36V 350W 1-Pack	1 × MEANWELL UHP Series Power Supply (36V / 350W), user manual
48V 350W 1-Pack	1 × MEANWELL UHP Series Power Supply (48V / 350W), user manual
5V 500W 1-Pack	1 × MEANWELL UHP Series Power Supply (5V / 500W), user manual
12V 500W 1-Pack	1 × MEANWELL UHP Series Power Supply (12V / 500W), user manual
24V 500W 1-Pack	1 × MEANWELL UHP Series Power Supply (24V / 500W), user manual
36V 500W 1-Pack	1 × MEANWELL UHP Series Power Supply (36V / 500W), user manual
48V 500W 1-Pack	1 × MEANWELL UHP Series Power Supply (48V / 500W), user manual

About this item

Slim and low-profile housing: 26mm thickness for 200W, 31mm for 350W/500W
Fanless design: 200W supports convection cooling; silent operation for compact installations
Wide input AC 90–264V with built-in active PFC function
Withstands 300VAC surge input for 5 seconds for improved input resilience
150% peak load capability (100ms) to handle short-term load spikes
Operating temperature range: -20°C to 70°C for demanding environments
Protections: short circuit, overload, over voltage, over temperature
DC OK active signal and redundant function available (optional, model-dependent)
Operating altitude up to 5000 meters (note requirement may apply)
LED power-on indicator and 3-year warranty

Order & Logistics

Lead Time: Ships within 1–3 business days.
Packing: Cardboard box.
Shipping Note: This series enjoys our Free Shipping Policy for orders over $399. Most items in this series are stocked in our local warehouses in the US, UK, and Germany for 3–7 day delivery. If an item is out of stock locally, it will ship from our headquarters warehouse: 9–18 days standard or 5–9 days express.

Key Specifications

Input Voltage: AC 90–264V, 50/60Hz
Output Voltage Options: 5V DC / 12V DC / 24V DC / 36V DC / 48V DC
Output Power Options: 200W / 350W / 500W
Profile Thickness: 26mm (200W); 31mm (350W/500W)
Cooling: Fanless; 200W convection cooling
Active PFC: Built-in active PFC function
Surge Withstand: 300VAC input surge for 5 seconds
Peak Load: 150% peak load capability (100ms)
Operating Temperature: -20°C to 70°C
Altitude: Up to 5000 m (note requirement may apply)
Protection: Short circuit, overload, over voltage, over temperature
Indicator: LED power-on indicator
Certification: UL / CE
Warranty: 3 years

Technical Specifications

Model	UHP-200-5	UHP-200-12	UHP-200-24	UHP-200-36	UHP-200-48	UHP-350-5	UHP-350-12	UHP-350-24	UHP-350-36	UHP-350-48	UHP-500-5	UHP-500-12	UHP-500-24	UHP-500-36	UHP-500-48
Rated output voltage	5V DC	12V DC	24V DC	36V DC	48V DC	5V DC	12V DC	24V DC	36V DC	48V DC	5V DC	12V DC	24V DC	36V DC	48V DC
Rated output current	40A	16.7A	8.4A	5.6A	4.2A	60A	29.2A	14.6A	9.75A	7.3A	80A	41.7A	20.9A	13.9A	10.45A
Output current range	0–40A	0–16.7A	0–8.4A	0–5.6A	0–4.2A	0–60A	0–29.2A	0–14.6A	0–9.75A	0–7.3A	0–80A	0–41.7A	0–20.9A	0–13.9A	0–10.45A
Rated output power	200W	200.4W	201.6W	201.6W	201.6W	300W	350W	350.4W	351W	350.4W	400W	500.4W	501.6W	500.4W	501.6W
Ripple & noise (max)	200mVp-p	240mVp-p	240mVp-p	240mVp-p	300mVp-p	200mVp-p	200mVp-p	240mVp-p	240mVp-p	240mVp-p	200mVp-p	200mVp-p	240mVp-p	360mVp-p	360mVp-p
Efficiency (typ.)	91%	93%	94%	94%	94%	90%	91%	92%	94%	94%	94%	94%	94.5%	95%	95%
Input voltage range	AC 90–264V / DC 127–370V
Frequency range	47–63Hz
Product dimensions (L × W × H)	194 × 55 × 26 mm					220 × 62 × 31 mm					232 × 81 × 31 mm
Operating temperature	-30°C to +70°C
Protection	Short circuit / Overload (110%–140%) / Over voltage / Over temperature
Cooling	Built-in cooling fan (forced air cooling)
Safety & compliance	UL / TUV / CE / BIS / EAC (model dependent)

Usage Notes / Installation Tips

Confirm the required DC output voltage (5V/12V/24V/36V/48V) before ordering
Select wattage based on total load and keep headroom for stable operation
Disconnect AC power before wiring or adjusting terminals
Provide adequate ventilation and avoid sealing the unit in an unventilated enclosure
Follow local electrical codes when integrating into systems or cabinets

Applications

Industrial control systems and automation equipment
LED lighting systems requiring stable DC output
Test benches, labs, and electronic prototyping
3D printers, CNC peripherals, and DIY electronics
Communication equipment and embedded systems
