Colorlight i5+ Receiving Card for LED Display Screens – 512×384 Pixels | Compact DDR2 SODIMM Interface with 32 Data Groups

Package Included

Version	Package Included
i5+	1× i5+ Receiving Card 1× Antistatic Bag 1× User Manual

High-end receiving card for fine-pitch LED screens; supports up to 32 parallel or 32 serial RGB data groups
Compact form factor; DDR2 SODIMM interface integrates with HUB boards and LED display modules for flexible designs
Per-card loading capacity up to 512×384 pixels; dynamic frame rate 23.976–240 Hz
Grayscale refinement, independent gamut adjustment, low latency, automatic OSD, loop backup, and smart module support
Compatible with irregular displays; supports cabinet monitoring and network cable detection
Ideal for concise cabinets in fixed installations, rental LED walls, and creative LED setups

Lead Time: Typically ships within 2–5 business days
Packing: Cardboard box
Shipping: Orders in this series qualify for our Free Shipping Policy on purchases over $399. All products in this series are shipped directly from our headquarters warehouse（Standard Shipping: 9–18 days|Express Shipping: 5–9 days.）

Interface: DDR2 SODIMM (receiving card to HUB/module)
RGB Data Groups: Up to 32 parallel or 32 serial
Supported Resolution (per card): Up to 512×384 pixels
Control Method: Connected via sender/controller over network within LED system
Power Supply: DC 3.3 V (provided by LED cabinet/system)
Operating Temperature: As per manufacturer standard

Always power off the LED system before installing or removing the receiving card
Use shielded network and ribbon cables for stable signal transmission
Ensure adequate ventilation inside the LED cabinet for prolonged operation
Use anti-static protection when handling; avoid ESD exposure

Model	i10	i9+	i8	i5+
Loading Capacity (pixels)	512×512	512×512	512×384	512×384
RGB Parallel Data Groups	32	32	32	32
Color Depth	8-bit / 10-bit / 12-bit	8-bit / 10-bit	8-bit / 10-bit	8-bit / 10-bit
Dynamic Frame Rate	23.976–240 Hz	23.976–240 Hz	23.976–240 Hz	23.976–240 Hz
Grayscale Refinement	√	√	√	√
Multi-layer Calibration	√	√	✘	✘
Infi-bit	√	√	√	✘
Independent Gamut Adjustment	√	√	√	√
HDR	√	√	√	✘
Low Latency	√	√	√	√
Automatic OSD	√	√	√	√
Loop Backup	√	√	√	√
Receiving Card Backup	√	√	√	√
Calibration Coefficient Backup	√	✘	√	✘
Configuration Parameter Backup	√	✘	√	✘
Smart Module	√	√	√	√
Irregular Display	√	√	√	√
Cabinet Monitoring	√	√	√	√
Network Cable Detection	√	√	√	√
